FSB ( FRONT SIDE BUS ): 1333/1066/800 MHz
Socket do processador: 775
Cache máximo suportado: N/A
Chipset: G41
Barramento de memória suportado: DDR3
Memória máxima suportado: Até 8 GB
Numero de socket de memoria: 2x soquetes DDR3 DIMM 240-pinos
Dual channel: Sim
Memoria de vídeo: Onboard
Tipo de vídeo: GMA X4500
Tipo de áudio: VIA® VT1705 6-channel audio CODEC
Rede: RealTek 8103EL 10/100 Fast Ethernet NIC
Slot de expansao:
- 1x PCI Express x16 slot
- 1x PCI slot
Painel da placa mae:
- 1x PS/2 keyboard & PS/2 mouse connectors
- 1x D-sub(VGA)
- 1x RJ45 LAN connector
- 1x Audio port (Line-in, Line-out, Mic-in)
- 4x USB 2.0 Ports
Conectores internos:
- 1x 24-pin ATX Power Supply connector
- 1x 4-pin CPU_FAN connector
- 1x Front panel switch/LED header
- 1x Front panel audio header
- 1x CLR COMS
- 1x 4-pin power connector for VGA card
- 2x SATA ports
- 2x USB 2.0 headers support additional 4 USB Ports
Portas firewire (1394): Nao
Portas USB: 6x USB 2.0
RAID: Nao
Alimentaçao: ATX 24 pinos
Dimensoes: Micro-ATX 225mm x 170mm
